SOG Vertical Inline Pump (API610/OH3)
SOG Vertical Inline Pump (API610/OH3)
Model：API610 OH3
Standard：API610
◉ Parameters:
Capacities：Q～1000 m3/h
Heads：H～180 m
Temperatures：T-30℃ ～230℃
Pressure：P～5.0 MPa
◉ Feature:
Single stage, single suction radial impeller, radially split volute. Axial suction, axial discharge, the center of suction and discharge ports are located on the same horizontal line, vertical installation, small footprint, easy installation. The pump has a separate bearing frame and the bearings are grease lubricated. The pump and motor are mounted on an integral bracket and connected by a flexible coupling with an extended section.
◉ Application:
Clean or slightly polluted, low or high temperature, chemically neutral or corrosive liquids;Refinery, oil and gas production, petrochemical chemical industry, coal chemical industry, pipeline pressurization and offshore platforms and other fields with limited workspace.
-
